RT 501
Toggle Type
Reliable and rigid construction for powerful, maintenance-free operation.
Durability that comes from a highly rigid structure.
Ideal for tasks requiring strong pressure, powerful bending, and punching thin sheets.
Compact design that saves space.
…………………………………………………………………………………………………………………………………….
■ Specifications
| Model | RT 501 | |
|---|---|---|
| Maximum Thrust | kN | 5.0 |
| Advancing Stroke | mm | 30 |
| Lever Rotation Angle / Stroke | °/mm | 75 |
| Maximum Weight of Upper Tooling | kg | 0.5 |
| Overhang Amount | mm | 75 |
| Main Shaft Ram Hole Diameter × Depth | ømm | 10H7×25 |
| Work Height | mm | 60〜190 |
| Frame Height | mm | 360 |
| Table Size | mm | 120×80 |
| Table Hole Diameter | mm | ー |
| Table Height | mm | 56 |
| Mounting Size | mm | 140×225 |
| Weight | kg | 20 |
…………………………………………………………………………………………………………………………………….
■ Option
| Model | RT 501 | |
|---|---|---|
| Nickel-Plated Specification | ● | |
| Distance Block Set | ● | |
| Mechanical Counter | ー | |
| Left Handle | ー | |
| Crank Handle | ● | |
| Fine Adjustment Mechanism (1 scale: 0.02 mm) |
ー | |
| Return Stroke Lock Mechanismt | ー | |
| Digital Load Indicator “Forster” | ● |
…………………………………………………………………………………………………………………………………….
